International / Farmall - Fits: M (When converted using 400 Gas inner/outer timing covers), [ MTA, Super M, Super MTA, Super W6, Super W6TA, Super W9, T6, 400, 450 (Gas/LP) ], Super WD9, W6 (When converted with 400 Gas inner/outer timing covers), [ W9, WD9 (when converted using Super W9, Super WD9 inner & outer timing covers) ], 600, 650; Replaces: 128190C91, 357214R92, 362175R94
NOTES: Equipped w/ longer drive shaft to run optional hour meter off the front timing cover. If your tractor is not equipped w/ this you may have to trim 1/2" off end of shaft for clearance.
Fits gas and LP only, does NOT fit diesels.
12.6 GPM @ 1450 RPM
1200 PSI
Mounting bolt pattern:
3-3/8" top center to center
2-5/8" bottom center to center
May need gaskets: ABC556 & ABC4704
IHS1240 port block sold separately
